HJ961BD Automatic Tire Inflator Machine

HJ961BD Automatic Tire Inflator Machine

  • Product Code: HJ961BD Automatic Tire Inflator Machine

With our automatic tire inflators, technicians don't have to wait by the tire changer while the tire inflates.
Inflation can be carried out off the tire changer, so the technician can be changing the next tire while inflation occurs.
For the average shop, this can mean 5%-10% more jobs per day.
Just set the pressure, attach the chuck, and press Start, HPMM tire inflator does the rest.

Features of product

  • Preinstalled electron pressure display,safety,accurate and easy operation
  • With the function of OPS over inflation and N2P cycle inflation
  • Automatic discharge when over inflation
  • Automatic air inflation with high speed and high level of accuracy
  • Buzzing and lighting alarm appears after finishing inflation
  • Tyre bead is not sealed with the tyre rim,the loose clamping mouth ,the leakage pipeline and air leakage,all the situation above will lead to lighting and automatic alarm during the air inflation. And the inflator can proceed texting job three times at most. The inflator will not execute all the inflation order until the stoppages are absolutely removed.
  • Adopting pressure sensor of high accuracy. accuracy2%(full scale reading)
  • IP54 level waterproof design,which is attractive and durable.

Voltage:220V  50/60Hz 1PH

Power:≤44W

Length of air inflator tube:10 meters

air inlet pressure:4 ~ 10 & 10 ~ 16 bar   / 58 ~ 145 & 145 ~ 232 PSI

inflation pressure:1 ~ 7 & 7 ~ 13 bar   / 15 ~ 102 & 102 ~ 188 PSI

tolerance for inflation pressure :±0.02 bar

working temperature:-20℃~70℃

relative humidity:10%RH~95%RH non-condensing

inflation speed:400L/Min(10Bar)
