3.0 T Capacity U-B30M ultra-thin wheel free scissor lift

3.0 T Capacity U-B30M ultra-thin wheel free scissor lift

The U-B30M mid-rise scissor lift is one of the most economical, unique, versatile & convenient vehicle lifting solutions in the market today. The U-B30M mid-rise scissor lift is a low-profile, lightweight,portable 3000KG capacity low-rise scissor frame contact tilt lift designed for unibody typepassenger & small sport utility vehicles. Equipped with twin dual-action precision gear drive mechanisms, the lifting operation is simply powered by the torque supplied from an electrichandheld drill. Additionally, the ‘exclusive’ dual independent safety lock bars also allow for fulloperation from either side of the lift. The unique vehicle ‘lift & tilt’ operation provides greateroverall accessibility to vehicle, while also being able to quickly & conveniently be stored out ofthe way. Designed for multi-use applications, the U-B30M mid-rise scissor lift can be widely used inresidential garages, auto service shops, autobody repair centers, car dealers or for detailing.


  • Product Code: Ultra-Thin Wheel Free Scissor Lift

Safety Features:

1.Chine Application

A low rise scissor lift can lift each kind of vehicle whose weight is less than 3000kg, suitable for use in vehicle tests, maintenance, and caring for automobiles, which is particularly suitable for use in the basement or on the floor, without construction and hole.

Lifts are designed and built to lift vehicles and hold them in an elevated position in an enclosed workshop. All other uses of the lifts are unauthorized. In particular, the lifts are not suitable for:

-Washing spray work; -Use in outdoors;

-Creating raised platforms for personnel or lifting personnel;

-Use as a press for crushing purposes; -Use as elevator;

-Use as a lift jack for lifting vehicle bodies or changing wheels.

The manufacturer is not liable for any injury to persons or damage to vehicles and other property caused by the incorrect and unauthorized use of the lifts.

2. Structure Features

-Use hidden and thin scissor structure, dispense with construction and ground hole, the occupation is small -Independent control box, low-voltage controlling, good security -Same hydraulic cubage and in-phase cylinder, the synchronization of platform

-With hydraulic lock and mechanical dual-gear safety-claw lock double safety device automatically open when lowering. Lock operation can have the safety-claw located, adversely, safe & reliable.

-Own protection of safety valve and burst-proof equipment for hydraulic failure and overloading. So when the oil pipe bursts, the machine will not fall quickly. -Sliding blocks adopt oil-free super-wearable materials.

-Use high quality hydraulic or electric element parts made in Italy, Germany, Japan, and so on.

-Own manual lowering operation when the power is cut.

3. Equipment

-Machine basement (The position and space of equipment installation)

-Machine frame (The main structure of lift and insurance institution)

-Control box (Machine-controlled part)

4. Frame Make of base plate, connecting rod, main lifting platform, hydraulic oil cylinder, and loading dock board


Scissor Lift
Product Ultra-Thin Wheel Free Scissor Lift
Product Code B30M
Capacity 3.0 T
Lifting height 980 mm
Min height 180 mm
Platform length 1600 mm
Power supply 3PH~380V, 50Hz,10A
Release Electrical hydraulic
