No excavation. No pit. No permanent floor modification. The U-B35Y No-Pit Scissor Lift brings the full access and workflow advantages of scissor lift servicing to workshops that can't — or won't — cut into their floor. Surface-mount installation means the U-B35Y is operational from day one, repositionable if the workshop layout changes, and available to every workshop regardless of floor type, tenancy restrictions, or budget constraints around civil works. Three thousand five hundred kilograms of lifting capacity. One hundred and five millimetres of minimum height. Fifty-five seconds to full service height. The scissor lift installs as easily as any other piece of workshop equipment.

The U-B35Y is a professional surface-mount scissor vehicle lift engineered for automotive workshops, tyre and service centres, and fleet maintenance facilities that need scissor lift capability — the vehicle access, platform working surface, and low-profile loading height that the scissor format provides — without the civil engineering commitment, floor disruption, and installation downtime of a pit-mounted system. With no ditch required, a 3,500kg rated capacity, 1,950mm lifting height, adjustable platform length from 1,500mm to 2,160mm for long wheelbase vehicles, pneumatic lock release with precision machined safety lock, electromagnetic lowering, synchronized four-cylinder hydraulic system, and a ≤55-second lift cycle, the U-B35Y delivers professional scissor lift capability in a surface-mount installation format that any workshop can accommodate.

No Ditch Needed — The Installation Advantage That Defines This Lift
The U-B35Y's "no ditch needed" surface-mount design is the feature that removes the primary barrier to scissor lift ownership for the majority of automotive workshops. Conventional pit-mounted scissor lifts require significant civil engineering work before installation can begin — concrete cutting, pit excavation, drainage management, concrete reinstatement, and the associated cost, downtime, and permanent floor modification that these works entail. For workshops in leased premises where floor modification requires landlord approval, for facilities with concrete floors over heating, drainage, or electrical infrastructure, for operations that need a lift operational immediately rather than weeks after civil works complete, and for workshop owners who simply cannot justify the additional cost of pit installation alongside the lift itself — the U-B35Y's surface-mount format removes every one of these barriers in a single design decision.

The U-B35Y sits on the existing workshop floor surface, requires no excavation, no concrete work, and no permanent modification to the floor or building structure — and delivers the same scissor lift working advantages of platform access, low-profile loading, and full-width vehicle support that pit-mounted alternatives provide, in a format that installs like any other workshop equipment.

Adjustable Platform Length — 1,500mm to 2,160mm for Long Wheelbase Vehicles
The U-B35Y's adjustable platform length is a practical versatility feature that distinguishes it from fixed-platform scissor lifts. The ramp section is fixable as an extendable platform — allowing the working surface to extend from 1,500mm standard length to a maximum of 2,160mm — accommodating the longer wheelbases of larger passenger vehicles, SUVs, and light vans that would overhang or be incompletely supported on shorter fixed platforms. For workshops servicing a diverse vehicle range that includes longer wheelbase models, the adjustable platform ensures the U-B35Y provides correct, full vehicle support on every vehicle type within its 3,500kg capacity — without the need for additional adapter equipment or platform extension accessories.

Precision Machined Safety Lock — Reliable Mechanical Security at Every Position
The U-B35Y's precision-machined safety lock provides positive mechanical locking at the lift's operational heights, with the machined precision of the locking mechanism ensuring consistent, reliable engagement and release throughout the lock's service life. Precision-machined components maintain dimensional accuracy and consistent locking force across years of repeated operational cycles — delivering the dependable safety lock performance that professional workshop lifting demands without the wear-related degradation that less precisely manufactured locking systems can develop under high-cycle commercial use.

Pneumatic Lock Release — Convenient, Responsive Latch Control
The U-B35Y's pneumatic lock release provides air-powered latch control — responsive, convenient, and consistent across the full range of lift positions. The pneumatic release system provides immediate, reliable latch disengagement with the precision-machined safety lock's consistent mechanical engagement quality — combining pneumatic operating convenience with precision mechanical safety lock integrity for a release system that is both easy to use and mechanically reliable at every lift height.

Electromagnetic Lowering — Controlled Descent From Service Height
The U-B35Y's electromagnetic lowering system controls platform descent with smooth, regulated hydraulic management throughout the full 1,950mm lowering travel — providing predictable, even descent that protects the vehicle, the platform surface, and workshop equipment from the variable, uncontrolled descent characteristics of unregulated lowering systems. For service operations where the vehicle's position and suspension geometry must be preserved during lowering — including post-alignment checks, suspension work, and brake service — electromagnetic control of the descent rate maintains the precision that the service procedure requires through to ground contact.

Synchronised Four-Cylinder Hydraulic System — Level Platform Under Any Load
The U-B35Y's synchronised four-cylinder hydraulic system drives all four lifting cylinders in coordinated hydraulic synchronisation — maintaining a level, stable platform surface throughout the full lift cycle regardless of vehicle weight distribution across the platform. For the diverse passenger car, SUV, and light commercial vehicle range the U-B35Y is designed to service, the four-cylinder synchronized system ensures that front-heavy, rear-heavy, and asymmetrically loaded vehicles are all lifted on a consistently level platform — preventing the differential height and platform tilt that unsynchronized or two-cylinder systems can develop under variable vehicle weight placement.

105mm Minimum Height — Exceptional Low-Profile Ground Clearance
The U-B35Y's 105mm minimum platform height is among the lowest in the vehicle lift lineup — providing the drive-on clearance needed for low-profile passenger vehicles, sports cars, and performance vehicles with minimal ground clearance that cannot load onto higher-minimum-height platforms without contact risk. At 105mm, the U-B35Y accommodates the full range of passenger vehicles from standard height to low-slung sports cars without front splitter, bumper, or underbody contact during drive-on loading.

≤55-Second Lift and Lower Cycle — Efficient Workshop Throughput
The U-B35Y's specified ≤55-second lift and lower cycle times — faster than the U-S55's ≤75-second main platform cycle — provide efficient, planned workshop throughput performance for the service bay. In a tyre, mechanical, or general service operation processing multiple vehicle lifts per shift, the 55-second cycle time gives service managers a reliable basis for bay time allocation and vehicle throughput scheduling — knowing exactly how long the lift contributes to each service cycle.

Optional Equipment — Extend for Specific Service Requirements

Optional Drive-by-Wire Button — provides remote pneumatic control operation for operators who need to manage the lift from a different position than the standard control station — adding operational flexibility for specific service procedures or bay layouts where the standard control position is inconvenient.

Optional Photoelectric Leveling System — provides automatic precision level verification using photoelectric sensors — valuable for any service procedure where platform level affects measurement or work quality, including any alignment-related use, suspension geometry work, or precision mechanical service.

Optional SUV Adapter — extends the U-B35Y's vehicle compatibility to larger SUVs and higher-ground-clearance vehicles where standard platform support point positioning needs adjustment — ensuring correct, stable support on the full range of larger passenger vehicles within the lift's capacity rating.

Safety System — Four Active Protective Mechanisms

1. Precision machined safety lock — positive mechanical locking at operational heights with dimensionally precise, wear-resistant lock geometry
2. Synchronized four-cylinder hydraulic system — maintains platform level and structural integrity under variable vehicle weight distribution
3. Secondary descent stop and CE STOP alarm — independent backup descent halt with immediate audible and visual alert if primary lower limit system fails
4. Height limit switch — automatic power cutoff at maximum safe platform height, preventing over-travel
5. Safety valve for anti-explosion of hydraulic system — prevents uncontrolled hydraulic pressure release at 3,500kg platform load
